Zebra S4M User Manual

Specifications
General Specifications
126
13290L-004 Rev. A S4M User Guide 6/15/09
General Specifications
General Specifications
Height 11.6 in. 295 mm
Width 10.7 in. 272 mm
Depth 18.8 in. 477 mm
Weight (without options) 27.2 lbs. 12.4 kg
Electrical 90–264 VAC, 47–63 Hz, 3 Amps (100 W)
Temperature Operating 40° to 104°F 5° to 40°C
Storage –40° to 140°F –40° to 60°C
Relative Humidity Operating 20% to 85%, non-condensing
Storage 5% to 85%, non-condensing
Communication Interface • RS-232/CCITT V.24 serial data interface; 300 to
115000 baud, parity, bits/character, 7 or 8 data
bit, and XON-XOFF, RTS/CTS or DTR/DSR
handshake protocol required. 750mA at 5 V
from pins 1 and 9.
• USB 1.1 data interface
• One of the following:
• 8-bit parallel data interface; supports IEEE
1284 bidirectional parallel; nibble mode
compliant.
• 10/100 internal Ethernet
• 802.11b/g wireless card support

Zebra S4M Specifications

General

Flash memory	4 MB
Internal memory	8 MB
Dimensions (WxDxH)	272 x 477 x 295 mm
Media types supported	continuous, die-cut, tag, black mark
Media thickness	0.076 - 0.15 mm
RS-232 ports	1
Standard interfaces	USB 2.0
Storage temperature (T-T)	5 - 40 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Weight	12400 g
