Zebra S4M User Manual

41
Operations
Print Modes and Printer Options
6/15/09 S4M User Guide 13290L-004 Rev. A
Fanfold Media
To insert fanfold media, complete these steps:
1. Flip down the media supply guide.
2. Insert the fanfold media through the fanfold media slot on the rear of the printer.
3. Drape the media over the media supply hanger.
4. Flip up the media supply guide, and then slide it in until it touches, but does not restrict,
the edge of the media.
5. Continue with the media loading procedure for the desired print mode.

Zebra S4M Specifications

General

Flash memory	4 MB
Internal memory	8 MB
Dimensions (WxDxH)	272 x 477 x 295 mm
Media types supported	continuous, die-cut, tag, black mark
Media thickness	0.076 - 0.15 mm
RS-232 ports	1
Standard interfaces	USB 2.0
Storage temperature (T-T)	5 - 40 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Weight	12400 g
