3D Microscopy
Eyepiece version Axiovert 100/135/135 M
24 B 40-022-4 e 09/98
3 Monitor version
The following components from KAPPA are
required for the monitor version:
MCU II control unit
CF 15/4 MC-S camera
CF 15/4 connecting cable to MCU II
Line cable
Monitor (100 Hz) with connecting cable and
attached monitor shutter
Control unit for monitor shutter, with power
unit and connecting cable
3D illumination shutter
Control and supply cable between MCU II
and 3D illumination shutter/monitor shutter
Polarizing glasses
Fig. 9 Wiring diagram for monitor version
