5-24
16. DISC TYPE JUDGEMENT WAVEFORM (DVDRW)
17. SPINDLE WAVEFORM1
FDRV(LIC502 PIN 5)
FE(LIC201 PIN87)
TE(LIC201 PIN85)
RF(LIC201PIN 113)
MDRV (LIC502 PIN 26)
REFOUT (LIC502 PIN 42)
SFG((LIC502 PIN43)
