JesterML Operating Manual Introduction
6 of 73 73-406-00 Issue 2.0
Master Controls and Displays
These controls set the general operating conditions for the desk.
MODE
The MODE button is used to select the operational mode of the desk. The red LEDs
to the left of the button show the current operating mode (SETUP, PRESET,
PROGRAM, RUN).
GRAND MASTER
The GRAND MASTER fader is used for overall control of the maximum output levels
from all brightness channels of the desk.
BLACKOUT
The BLACKOUT button makes all the brightness channels output zero. Pressing the
BLACKOUT button toggles between Blackout (all channels at zero) and normal desk
outputs. The LED in the BLACKOUT button indicates the current state (Flashing =
