General Operation
4.20
Spring Pre-load Adjustment
1. Clean any dirt or debris from the threads of the shock
near the lock ring (A).
2. Using a lock ring wrench loosen the lock nut (A).
3. For measurements less than the specified value,
decrease the pre-load on the spring by turning the
spring nut (B) counter-clockwise on the shock. If more
than the specified value, increase the pre-load on the
spring by turning the spring nut (B) clockwise on the
shock.
