Bearing capacity of rear tires
Note:
The specified inflation values are minimum valued adapted to the current tyre load so that the tyre
deformation can remain in the range in which all the operation requirements are met.
Change of the load capacity of the rear tyres (%)
Tyre
dimensions
Travelling speed
40 km.h
-1
30 km.h
-1
20 km.h
-1
8 km.h
-1
Tyreload-
bearing
capacity (kg)
Tyreload-
bearing
capacity (kg)
Tyreload-
bearing
capacity (kg)
Tyreload-
bearing
capacity (kg)
Tyre
1 pc
Axle Inflation
(kPa)
Tyre
1 pc
Axle Inflation
(kPa)
Tyre
1 pc
Axle Inflation
(kPa)
Tyre
1 pc
Axle Inflation
(kPa)
650/65R38 3000 6000 70 3000 6000 60 3000 6000 55 3500 7000 60
580/70R38 3000 6000 95 3000 6000 80 3000 6000 80 3500 7000 80
18,4R38 3000 6000 160 3000 6000 145 3000 6000 120 3500 7000 120
520/70R38 3000 6000 140 3000 6000 120 3000 6000 95 3500 7000 110
600/65R38 3000 6000 100 3000 6000 90 3000 6000 65 3500 7000 80
Performance on rear PTO shaft
Travelling speed (km/h) diagonal radial
8 + 40 + 50
20 + 20 + 23
30 0 + 7
40 - 20 0
Lifting force of the three-point hitch
Power Typ traktoru
FORTERRA
HD 130
FORTERRA
HD 130
FORTERRA
HD 140
FORTERRA
HD 140
FORTERRA
HD 150
PTO power (kW ± 2%)
at the nominal engine speed and
engaged 1000 rpm of the PTO
Engine type (TIER III B) Z 1506 Z 1516 Z 1606 Z 1616 Z 1716
Engine in the running-in stage
(until 100 hours)
75,4 75,4 80,8 80,8 88,2
Engine after the running-in stage
(from 100 hours on)
78,6 78,6 84,2 84,2 91,7
Lifting force at the end of the bottom
draw-bars of the rear three-point hitch in
the whole lifting range at the maximum
usable pressure (kN).
76
Lifting force at the end of the lower draw-
bars of the front three-point hitch in the
whole lifting range at the maximum
usable pressure (kN) - Zuidberg front
three-point hitch
35
MAIN TECHNICAL PARAMETERS
