209
MAINTENANCE INSTRUCTIONS
G749
GEARBOX DISTRIBUTOR – REPLACEMENT OF OIL CLEANER CARTRIDGE
The gearbox distributor is located on the right side of the tractor behind the fuel tank;
the oil cleaner is accessible from the bottom of the tractor.
Before replacement of the oil cleaner cartridge, put a suitable container un-
der the tractor to catch any leaking oil.
1. Screw out the cleaner body (1).
2. Replace the filtration cartridge (2).
3. Reinstall the cleaner body (1).
DIESEL PARTICLE FILTER
MAINTENANCE
Leave the maintenance of diesel
particle filter to an authorized ser-
vice.
