ACQUAINTANCE WITH TRACTOR
DASHBOARD
DEVICES DESCRIPTION
A - Indicators
B - Air pressure gauge
C - speedometer
F - fuel gauge
G - coolant thermometer
H - display
INDICATORS
1 - High beam lights (blue). Lights up
when high beam headlights are on.
2 - Tractor turn signal indicator (green)
3 - 1st trailer turn signal indicator (green)
4 - 2nd trailer turn signal indicator
(green)
5 - Indicator of minimum air pressure in
the brake system (red). Lights up if
the air pressure for the air brakes of
the trailer drops below the critical lim-
it, i.e. 450 kPa.
6 - Parking brake (red). Lights up when
the parking brake lever is in the “on”
position.
7 - Charging. During engine operation it
lights up in case of a charging failure.
If the engine is stopped, it must light
up. For more information see Electri-
cal installation chapter
8 - Lubrication (red). During engine op-
eration it light up if the engine oil
pressure drops below 120 to 60 kPa.
If the engine is stopped, it must light
up.
9 - Free
10 - Free
11 - Free
12 - Indicator of engagement of mul-
tiplier (green).
13 - Free
14 - Indicator of error signalization in the
system of hydrostatic steering (red)
With engine engaged lights up with
failure of hydrostatic steering. If en-
gine is at standstill, it must be lit.
15 - Fuel (orange). It is lit with residue of
1/6 - 1/10 of tank volume.
16 - Indicator of PTO engagement (or-
ange) is not engaged.
17 - Engine glowing (yellow). Signals ac-
tivity of device for easing the start of
engine.
18 - Diesel particle filter control
(green) , for more see chap-
ter „Driving operation“
19 - Free
20 - Warning indicator (red). Lights up with
pressure drop under critical limit i.e.
450 kPa, with engaged parking brake,
with charging failure, with low pres-
sure of oil in the engine or with brake
lining of the front brake wear off.
21 - Diesel particle filter control
(red), for more see “Driving
operation”
22 - Free
23 - Free
24 - Free
To Next Page
