10
Installation and Balance Adjustment
1. Tilt axis horizontal balance adjustment.
Unlock the tilt axis and Quick Release
Plate Latch, push the camera to move forward or backward until the camera can
stay still and almost level with its lens facing front (as shown below). Complete
this step by tightening up Quick Release Plate Latch.
2. Tilt axis vertical balance adjustment.
Make the lens face up, slightly loosen the
thumb screw of the tilt axis, and push the camera to move upward or downward
until the camera can stay still with the lens facing up. Complete this step by
tightening up the thumb screw.
