ZIEHL-ABEGG ECblue BASIC-MODBUS - Assembly Notes for Cable Glands

•
Remants from installation and foreign object may not remain on the inside!
Remants from installation, foreign objects and dirt has to be removed from the sealing area between
cover and controller housing!
Tightening torques M
A
Thread size Tightening tor-
ques M
A
Remarks
[Nm] [Lb In]
Plastic cable gland
M16 2.5 22
Sealing area for cables with outer diameter
4…10 mm
Plastic cable gland
M20 4 35
Sealing area with black seal insert for cables with
outer diameter 8… 12 mm
Sealing area with blue seal insert for cables with
outer diameter 6… 7.9 mm
Brass cable gland
M16 5 44
Sealing area for cables with outer diameter
5.5…10 mm
Brass cable gland
M20 6.5 58
Sealing area for cables with outer diameter
6…12 mm
Locking screw
M16 + M20 2.5 22
Slotted screwdriver
Cover of controller housing *
M4 2.5 22
Protective earth connection *
M4 2.5 22
Fastening add-on module *
M4 1.2 11
Terminals add-on module *
M2 0.24 2.2
* Recommended tightening speed maximum 400 min
-1
Connection data of terminals
Terminal
Voltage supply Brake control Add-on module
AM-
Stripping length 15 mm 10 mm 4 mm
Conductor cross-section rigid min. 0.2 mm
2
0.2 mm
2
0.2 mm
2
Conductor cross-section rigid max. 10 mm
2
1.5 mm
2
1.5 mm
2
Conductor cross-section flexible min. 0.2 mm
2
0.25 mm
2
0.2 mm
2
Conductor cross-section flexible max. 6 mm
2
1.5 mm
2
1.5 mm
2
Conductor cross section flexible with wire end ferrule
without plastic sleeve min.
0.25 mm
2
0.25 mm
2
0.25 mm
2
Conductor cross section flexible with wire end ferrule
without plastic sleeve max.
6 mm
2
1.5 mm
2
0.75 mm
2
Conductor cross section flexible with wire end ferrule
with plastic sleeve min.
0.25 mm
2
0.25 mm
2
0.25 mm
2
Conductor cross section flexible with wire end ferrule
with plastic sleeve max.
4 mm
2
1.5 mm
2
0.75 mm
2
Conductor cross-section AWG/kcmil min. 24 24 28
Conductor cross-section AWG/kcmil max. 8 16 16
The data refer to the connection possibilities of the terminals. The necessary conductor cross section must be
dimensioned according to the respective prevailing conditions.
UL: note for cable entrances
According to UL the attached locking screws (made of plastic) are acceptable for transport.
According to UL the supplied cable glands can be used without conduit when they are being used in
an installation according to NFPA79.
Quick Start Guide ECblue BASIC-MODBUS, ECblue BASIC Electrical installation
L-BAL-F078-GB 2024 Index 005 Part.-No. 00706648-GB
12/32
