1 General notes
Compliance with the following instructions is mandatory to ensure the functionality and safety of the
product. If the following instructions given especially but not limited for general safety, transport,
storage, mounting, operating conditions, start-up, maintenance, repair, cleaning and disposal / recy-
cling are not observed, the product may not operate safely and may cause a hazard to the life and
limb of users and third parties.
Deviations from the following requirements may therefore lead both to the loss of the statutory material
defect liability rights and to the liability of the buyer for the product that has become unsafe due to the
deviation from the specifications.
1.1 Validity
This document is valid for motors and fans of the ECblue series. Motor sizes D (116) and G (152).
The used motor size is recognisable from the type designation (see rating plate).
Examples for type designations with motor size D = 116
Motors Type Axial fans type Centrifugal fans type
MK116 -_ I _ . _ _ . _ _ F _ _ _ _-_ I _. D _._ _ _ _
D _ _ _ _-_ I _. D _._ _ _ _
Z _ _ _ _-_ I _. D _._ _ _ _
RH _ _ _-_ I _. D _._ _
GR _ _ _-_ I _. D _._ _
ER _ _ _-_ I _. D _._ _
WR_ _ _-_ I _. D _._ _
A total of 2 connection versions are available (see rating plate)
1. ECblue MB
ECblue BASIC-MODBUS
2. ECblue BASIC
Information
In the case of fans with the quality mark (see rating plate), please note the related specifications
depending on the application location!
1.2 Structure of the short operating instructions
Attention!
This Quick Start Guide contains basic information on safety, use, installation and commissioning.
This document explicitly does not replace the detailed assembly instructions that we provide for
download. The additional information contained therein must be observed.
To download, go to
https://bal.ziehl-abegg.com and enter the article number of the product. The
available language versions of the assembly instructions and the quick start guide are then displayed.
The detailed assembly instructions are marked with a “D”, see L-BAL-F078D.
Enter the product article number (see rating plate under P/N:)
xxxxxx
1.3 Exclusion of liability
Concurrence between the contents of these assembly instructions and the described hardware and
software in the device has been examined. It is still possible that non-compliances exist; no guarantee
is assumed for complete conformity. To allow for future developments, construction methods and
technical data given are subject to alteration. We do not accept any liability for possible errors or
omissions in the information contained in data, illustrations or drawings provided.
ZIEHL-ABEGG SE is not liable for damage due to misuse, improper use or as a consequence of
unauthorized repairs or modifi cations.
Quick Start Guide ECblue BASIC-MODBUS, ECblue BASIC General notes
L-BAL-F078-GB 2024 Index 005 Part.-No. 00706648-GB
3/32
