9 Enclosure
9.1 Technical data
Line voltage*
(see rating plate)
1 ~ 200...277 V, 50/60 Hz
3 ~ 200...240 V, 50/60 Hz
3 ~ 380...480 V, 50/60 Hz
3 ~ 200...480 V, 50/60 Hz
(Versions for DC power supply on request)
Maximal line fuse** 16 A for all types 1 ~ and 3~
Max. load limit integral of cut-in current
approx.
1,22 A
2
s
Switching Freq. 16 kHz
Input resistance for signal set for the
rotational speed
@ 0...10 V: R
i
= 300 kΩ
@ 4...20 mA: R
i
= 350 Ω
@ PWM: R
i
= 3 kΩ
Specification speed setting signal
PWM
Switching frequency: 1...10 kHz
On-off ratio: 0...100 %
U
in
high level: 15...28 V
U
in
low level: 0...10 V
Voltage supply for external devices +10 V, I
max
10 mA (short-circuit-proof)
+24 V ±20 %, I
max
70 mA (short-circuit-proof)
Digital input “D1” Input resistance: R
i
approx. 4 kΩ @ 24 V
U
in
high level: 7...30 V
U
in
low level: 0...2 V
Duty type of motor/fan Continuous operation with occasional starts (S1) according to DIN EN 60034-1:2011-
02.
Occasional starting between -35 °C and -25 °C is permissible.
Continuous operation below -25 °C only with special bearings for refrigeration applica-
tions on request.
Permissible minimal and maximal am-
bient temperature for operation
Please refer to the technical documentation of the product for the minimum and
maximum ambient temperature valid for the respective fan.
Operation below -25 °C as well as partial load operation for refrigeration applications is
only possible with special bearings for refrigeration applications on request. If special
bearings for refrigeration applications are installed in the fan, please observe the
permissible maximum temperatures in the technical documentation of the product.
To avoid condensation the drive must be continuously energized due to the application
of heat, with interruptions such that cooling to the point of condensation does not occur.
Permissible temperature range for
storage and transport
-40...+80 °C
Permissible installation height In “Constant speed mode”
0...4000 m amsl
≤ 1000 m: no limitation
> 1000 m: max. permissible input current = current indication rating plate minus 5 % /
1000 m
> 2000 m: max. permissible line voltage = max. voltage indication name plate minus
1.29 % / 100 m
In “Constant torque mode”
0...4000 m amsl
Max. permitted specification signal = 10 V (100 % PWM, 20 mA, MODBUS) minus
2.3 % / 1000 m
> 2000 m: max. permissible line voltage = max. voltage indication name plate minus
1.29 % / 100 m
Permissible rel. humidity The motor is released for a relative humidity of 100 % at continental climate without
other ambient influences. Other ambient conditions on request.
Quick Start Guide ECblue BASIC-MODBUS, ECblue BASIC Enclosure
L-BAL-F078-GB 2024 Index 005 Part.-No. 00706648-GB
