11.2 Occupant restraint instructions
WARNINGS!
The pelvic restraint belt must be worn low across the •
front of the pelvis (Fig. 11.2) so that the angle of the
pelvic belt is within the preferred zone of 30° to 75° to
the horizontal (Fig. 11.3).
A steeper (greater) angle within the preferred zone is •
desirable i.e. closer to, but never exceeding 75°.
Restraints should not be held away from body by •
wheelchair components such as armrests or wheels
(Fig. 11.4).
The upper torso restraint belt must fit over the shoulder •
and across the chest as illustrated (Fig. 11.5).
Restraint belts must be adjusted as tightly as possible •
consistent with user comfort
Restraint belt webbing must not be twisted when in •
use.
WARNINGS!
Restraints should not be held away from body by •
wheelchair components such as armrests or wheels.
Headrest should be positioned to support the back of •
the head fully and not rest in the nape of the neck.
Pelvic restraints should make full contact across the •
front of the body near the junction of the thigh and
pelvis
Fig. 11.3
Fig. 11.4
Fig. 11.5
