❷ Installaon
2.1 I Set-up
: Cleaner
: Hose secons
: Pool valves
: Sucon port
: Skimmer
: Filter pump
: Filter
Connecon example to the sucon port
2.2 I Assembling the hose secons
• Measure the length between the skimmer or sucon port and the most distant point in the pool.
• Add 1 extra metre to the length measured.
• If the total length is greater than 10 metres (T3 / R3 / B3) or 12 metres (T5 Duo), contact your retailer to purchase
addional hose secons.
: Connecon to the skimmer or sucon port
: Required hose length
: Addional 1-metre secon
: Connecon to the cleaner
Rectangular pool
Freeform pool
Tip: assemble the "right" quanty of hose secons
Assembling more hose secons than necessary to cover the enre pool is not recommended. A too long
hose could reduce the cleaner's eciency.
