3.4 I Electricity supply connecons
Please respect the following instrucons to prevent the risk of electrocuon, re or serious
injury:
• Use of an electrical extension is prohibited when connecng the control box.
• Make sure that the socket can be easily accessed at all mes and is protected from rain or
splashes.
• The control box is splash-proof but must not be immeresed in water or any liquid. It must not
be installed in a oodable area; keep it at least 3.5 metres away from the edge of the pool and
avoid exposing it to direct sunlight.
• Place the control box near the socket.
• Unscrew the protecve cap (see image ).
• Connect the oang cable to the control box and lock it in place by turning the ring only in the clockwise direcon (to
prevent damage to the oang cable) (seeimage
, ).
• Make sure that the connector is fully pushed in so that no water can get in (see image ).
• Connect the power cord (see image ). Only connect the control box to a power outlet protected by a 30 mA maxi-
mum residual current device (if in doubt contact a qualied technician).
Tip: choose the locaon of the control box carefully to prevent the cable from becoming tangled
Place the control box in the centre of the pool's length, following the safety condions relang to the
electrical connecon. This lets you limit the length of the oang cable to be put into the water to cover the
pool, which simplies set-up and storage operaons.
