Zodiac Vortex EC11 - ❹ Maintenance; I Cleaning the Cleaner; I Cleaning the Filter

17
4.3 I Replacing the brushes
• Each brush is equipped with wear indicators, the gap between the indicators and the end of the brush indicates that
the brush is in good condion (see image
).
• When the wear indicators appear as shown on the image , the brushes are worn and must be replaced.
• To remove worn brushes, remove the tabs from the holes in which they are xed (see image ).
• To t new brushes, start by ng the side without tabs under the brush holder (see image ).
• Roll the brush around its support, slide the tabs into the aachment holes and pull on the end of each tab unl its
edge passes through the slit (see image
).
• Cut the tabs using a pair of scissors for them to be level with the other blades (see image ).
