ZOLL M Series Service Manual

M Series Service Manual
9650-0450-01 Rev. U 4-5
14. Data transmission to and control over the System Interconnect PCB functions, including the stripchart recorder and the PCMCIA slot
functions.
Power Supply
The power supply converts DC power from a removable battery or the AC/DC Battery Charger module to voltages required by the M Series
hardware.
The power supply circuit converts the raw battery or the Charger PWBA output voltages of +8.5 VDC to +16 VDC into the voltages shown in the
table below, including load and line regulation.
VOLTAGE DESCRIPTION VOLTAGE VDC
(
Nominal)
COMMENTS
FUSE_PWR Fused Input Power from
Battery/Charger
12
SW_PWR Switched Input Power
after Power Switch
12
3VDD + 3.3 VDC Power for
Digital circuits
3.3 Switching @ 300 kHz
5VDD + 5.0 VDC Power for
Digital circuits
5.0 Switching @ 300 kHz
-5VSS - 5.0 VDC Power for
Analog circuits
-5.0 Linear
12VEE + 12.0 VDC Power for
Analog circuits
12.0 Linear
15VDD + 15.0 VDC Power for
VPP and 12VEE
15.0 Switching @ 300 kHz
LCD_BS LCD BIAS Power for
LCD display
- 18 Switching @ 100 kHz

ZOLL M Series Specifications

General

Pacer Rate	30 - 180 ppm
Display Type	LCD
Defibrillator Type	Manual and AED
Monitor Display	High-resolution LCD
ECG Monitoring	3-lead
Pacing	Demand
Battery Type	Lithium-ion
Display	High-resolution LCD
Waveform	Biphasic Truncated Exponential (BTE)
Monitoring Parameters	ECG, SpO2, EtCO2, NIBP, temperature
Connectivity	Data port for data transfer
Pacer Type	Transcutaneous
Pacer Output	0 - 140 mA
Printer	Integrated thermal
Energy Selection	2, 3, 5, 7, 10, 15, 20, 30, 50, 70, 100, 120, 150, 200 Joules
