ZOLL M Series Service Manual

1. Using an exacto knife, remove the latch seal. 2. Insert the screwdriver into the opening under the adhesive
seal. Gently push the screwdriver until the latch dislodges.
3. Pull paddle release latch away from the unit.
M Series Service Manual
9650-0450-01 Rev. U 5-33
Paddle Release Latch Removal

ZOLL M Series Specifications

General

Pacer Rate	30 - 180 ppm
Display Type	LCD
Defibrillator Type	Manual and AED
Monitor Display	High-resolution LCD
ECG Monitoring	3-lead
Pacing	Demand
Battery Type	Lithium-ion
Display	High-resolution LCD
Waveform	Biphasic Truncated Exponential (BTE)
Monitoring Parameters	ECG, SpO2, EtCO2, NIBP, temperature
Connectivity	Data port for data transfer
Pacer Type	Transcutaneous
Pacer Output	0 - 140 mA
Printer	Integrated thermal
Energy Selection	2, 3, 5, 7, 10, 15, 20, 30, 50, 70, 100, 120, 150, 200 Joules
