33
Specifications
Specifications
Effect types 86 types
Maximum number of
simultaneous effects
6
Number of patch memories
50
Sampling frequency 44.1kHz
A/D conversion 24-bit with 128x oversampling
D/A conversion 24-bit with 128x oversampling
Signal processing 32-bit floating point & 32-bit fixed point
Frequency characteristics
20-20kHz (+1dB/3dB) (10kΩ load)
Display LCD
Input Standard monaural phone jack x 2
Rated input level: 20dBm, Input impedance 1MΩ
Output Standard monaural phone jack x 2
Maximum output level: Line +5dBm (with output load impedance of 10 kΩ or more)
Power
AC adapter DC9V (center minus plug), 500 mA (ZOOM AD-16)
Batteries
Continuous operation using 2 AA alkaline batteries for about 7 hours with mono input or
about 5 hours with stereo input
USB
Dimensions 130.3mm(D) x 77.5mm(W) x 58.5mm(H)
USB Firmware update
Weight 360g
t0dBm=0.775Vrms

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zoom Multistomp MS-70CDR and is the answer not in the manual?

Zoom Multistomp MS-70CDR Specifications

General IconGeneral
Effects86
Patches50 user patches
DisplayLCD
Input1 x 1/4"
Output1 x 1/4"
Pedal TypeMulti-effects
Bypass SwitchingBuffered
TypeMulti-effects
Current Draw500 mA
Simultaneous EffectsUp to 6
Power9V DC
Effects TypesChorus, Delay, Reverb
Power Source9V DC
Presets50
