Zoom R8 Interface Manual

13
Audio interface manual
level meters
(Audio interface use)
Signal just before being
sent to computer shown
Signal returning from
the computer shown
Checking DAW recording levels
Set “
REC SIGNAL
” (in the
INSERT
EFFECT
menu) to set whether signals are
sent to the computer “
WET
” (with effect)
or “
DRY
” (without effect).
Adjust so that the
level meters do not
clip (reach 0 dB)
0 dB
(clipping)

Zoom R8 Specifications

General

Sample rate	96 kHz
Audio quality	24 bit
Microphone input impedance	1000 Ω
USB 2.0 ports quantity	1
Product color	Black

Weight and Dimensions

Weight	780 g
Dimensions (WxDxH)	257 x 190 x 51 mm
