Zoom R8 Interface Manual

15
Audio interface manual
Control surface functions quick reference guide
These functions work with Cubase LE, Cubase, Logic Pro, SONAR, Ableton Live and
Digital Performer.
Control Explanation
Fader section
Status keys
Turns mute, solo or record arming on/off for tracks
1–8 faders
Controls the volume of the corresponding tracks
MASTER fader Master volume operation
Display section Soft keys
Change functions of status keys, change banks and end
connection (EXIT)
Transport section
Cursor keys
Performs the same functions as the computer arrow keys
1
DIAL Moves the project cursor position
2
REW key Rewind
FF key Fast forward
STOP key Stop
PLAY key Play
REC key Record
AUTO PUNCH I/O key
Depends on the F1 key setting
A-B REPEAT key
Depends on the F2 key setting
(marker) key
Depends on the F3 key setting
(marker) key
Depends on the F4 key setting
MARK/CLEAR key
Depends on the F5 key setting
1
Scrolls window in Digital Performer
2
No function in Digital Performer

Zoom R8 Specifications

General

Sample rate	96 kHz
Audio quality	24 bit
Microphone input impedance	1000 Ω
USB 2.0 ports quantity	1
Product color	Black

Weight and Dimensions

Weight	780 g
Dimensions (WxDxH)	257 x 190 x 51 mm
