Edition 2 Chapter 1 Page 1-5
Feb/2013 Maintenance and Service
(2) Engine Oil Level
(a) You can measure the level of oil in the engine by a dipstick. The
dipstick is on the right side of the engine (aft end of the crane). The
engine must be OFF and sit for a short time before you can
measure the oil level. Wait for 15 minutes, after you stop the engine,
to measure the level. Adjust the level of oil to the full mark.
(b) Do not overfill!
Do not operate the crane if the level of engine oil is too low or too high.
(3) Water Separator
(a) The fuel line contains a water separator. It removes the
condensation and contamination from the fuel before it goes into the
engine. You must examine the water separator before you operate
the crane to drain the condensation and contamination.
(b) Do not let the water separator fill more than 1/2 full.
(4) Air Filter
(a) Examine the air filter and its connections for leaks, dents and
damage (See Figure 1-2).
Figure 1-2 Air Filter
