Edition 2 Chapter 1 Page 1-35
Feb/2013 Maintenance and Service
Do not wash the filter element!
(e) Examine the filter element. If it is dirty or full of contamination,
discard it. If this is a 1000 hours inspection, discard the element.
If you install a new filter element, replace the washer and O-ring.
(f) Assemble the fuel filter in sequence as follows (See Figure 1-24):
• Long central treaded bolt
• Washer (new)
• Fuel filter bowl
• Spring
• Spring seat
• Filter element (new)
• O-ring (new).
(g) Remove the air with manual oil pump.
(h) Examine the filter assembly for leaks.
Figure 1-24 Fuel Filter and Water Separator
