2N Helios IP Installation Manual

Electric Installation
2.3
24
Description of Connectors
X1
Loudspeaker
X4
Camera module
X5
Button 1
SW1
Reset button (555v3 version only)
X6
Configuration jumpers
X8
Extending module (RFID card reader or additional switch)
X10
Buttons 1 through 4
X11
LAN
X12
Servicing connector
X13
Keypad module
X15
Left-hand microphone
X16
Right-hand microphone
X17
Relay NO and NC contact
X18
12V/700 mA switched output
X19
12V/1A DC power input
LED1/2
System status indicators
LED3
LAN connection activity indicator
LAN Connection
2N
®
Helios IP Safety is connected to the LAN via a RJ-45 terminated (connector X11)
UTP/STP cable (of category Cat 5e or higher). The system is equipped with the Auto-
MDIX function and so both the straight and crossed cable versions can be used.
External Power Supply Connection
2N
®
Helios IP Safety can be fed either from an external 12V/1A DC power supply or
from the LAN equipped with the PoE 802.3af supporting network elements.
External Power Supply
An external 12V power supply is connected to terminal block X19. Use a 12V +- 15%
DC power source dimensioned to current intake of 1A at least (Part No. 91341481E) to
ensure a reliable function of your device.
PoE Supply
2N
®
Helios IP Safety is compatible with the PoE 802.3af (Class 0 – 12.95W)
technology and can be supplied directly from the LAN via compatible network
elements. If your LAN in incompatible, insert the PoE injector, Part No. 91758100E,
between 2N
®
Helios IP Safety and the nearest network element.

2N Helios IP Specifications

General

Type	IP Intercom
Connectivity	Ethernet
Tamper Switch	Yes
Audio	Full duplex
Microphone	Built-in
Speaker	Built-in
Camera	Yes
Power Supply	PoE
Operating Temperature	+60°C
Ingress Protection	IP54
Protocols	SIP, RTSP, ONVIF
Audio Codec	G.711, G.722
Installation	Surface mount, flush mount (depending on model)
