2N Helios IP Documentation

Helios IP – Documentation Page 2
Content
LIST OF TABLES 3
LIST OF FIGURES 3
DOCUMENT UPDATE HISTORY 4
DEVICE CONNECTION 5
DEVICE CONFIGURATION 5
API ACCESS 5
SIP ACCOUNT SETTING 7
SWITCH SETTINGS 8
DRIVER INFO 9
DRIVER HISTORY 9
HARDWARE COMPONENTS AND VERSIONS 9
HELIOS IP DRIVER CONFIGURATION 10
HELIOS IP BUS CONTROLLER 10
HELIOS IP BUS CONTROLLER SETTINGS 10
SWITCH SETTINGS 10
SUPPORTED HELIOS IP BUS CONTROLLER 11
SUPPORTED SWITCH COMMANDS 11
HELIOS IP INTEGRATION TESTS 12
PREPARATION OF INTEGRATION TESTS 13
NECESSARY COMPONENTS 13
DEVICE TREE CREATION 13
CENTRAL UNIT PREPARATION FOR TESTING 14
CONNECTION 14
BASIC FUNCTION TESTS 15
TCF000A DUPLICATE ADDRESS 15
TCF010A MISSING HW COMPONENT 16
TCF020A PARAMETER VALUE BEYOND RANGE 17
TRE000A CONNECTION LOSS 18
TRE010A COMMUNICATION LOSS 19
TFC010A CONTACT ACTIVATION/DEACTIVATION 20
T001 – CALL SETUP CHECK 21

2N Helios IP Specifications

General

Type	IP Intercom
Connectivity	Ethernet
Tamper Switch	Yes
Audio	Full duplex
Microphone	Built-in
Speaker	Built-in
Camera	Yes
Power Supply	PoE
Operating Temperature	+60°C
Ingress Protection	IP54
Protocols	SIP, RTSP, ONVIF
Audio Codec	G.711, G.722
Installation	Surface mount, flush mount (depending on model)
