Helios IP – Documentation Page 20
TFC010A Contact Activation and Deactivation
The test verifies the input/ouput contact control and monitoring.
Test Procedure
1. Click ON on the switch.
2. When the contact is activated, click OFF on the switch.
Expected Results
1. When the switch is activated, its state is marked Open.
2. When the switch is deactivated, its state is marked Normal.
3. The following events are recorded in the log:
Command ‘On’ send to ‘DEVICE’ by ‘PERSON’.
’DEVICE’ opened.
Command ‘Off’ send to ‘DEVICE’ by ‘PERSON’.
’DEVICE’ closed.
Where
 DEVICE is the switch name.
 PERSON represents the command entering person.

2N Helios IP Specifications

General

Type	IP Intercom
Connectivity	Ethernet
Tamper Switch	Yes
Audio	Full duplex
Microphone	Built-in
Speaker	Built-in
Camera	Yes
Power Supply	PoE
Operating Temperature	+60°C
Ingress Protection	IP54
Protocols	SIP, RTSP, ONVIF
Audio Codec	G.711, G.722
Installation	Surface mount, flush mount (depending on model)
