InputChanged
The block defines the event generated by a change of the logic level on InputChanged
the defined digital input.
Input parameters
Input – define the logic input.
Valid values:
tamper – tamper switch input
input1 – digital input 1
input2 – digital input 2
cr_input1 – digital input 1 on card reader
cr_input2 – digital input 2 on card reader.
There may be different lists of valid values for different intercom 2N IP
models; refer to the Available Digital Inputs and Outputs subsection.
Edge define the detected change on the digital input.
Valid values:
falling – falling edge, change from log. 1 to log. 0
rising – rising edge, change from log. 0 to log. 1.
The parameter is optional, the default value is .rising
Output parameters
Event – the Event invoke connected Event or Action.
Output the detected ID of the input whose change was the last to generate
this event. The options correspond to the Input parameter values.
Edge the detected edge change which was the last to generate this event. The
options are falling or rising.
Example
Event generated by disconnection of the tamper switch (device opening):
