ActivateSwitch
The block defines the action necessary for activation of the intercom ActivateSwitch
switch as configured in the Switch 1–4 tags. The activity to be performed depends
fully on the particular switch settings (digital output activation, HTTP command
sending, etc.). Switch deactivation is controlled by the switch settings too.
Parameters
Event – define the event to launch the action.
Condition – define the condition to be met to execute the action. This parameter
is optional.
Switch – define the switch to be activated (1 to 4).
State – define the state of the bistable switch (parameter does not apply for the
monostable switch mode).
Valid values:
on – the switch is activated.
off – the switch is deactivated.
toggle – the switch is toggled.
The parameter is optional, the default value is . on
Example
Activate switch 1 if the event defined on row 2 arises and the condition defined on row
3 is met:
