3-8
n Figure 3-16 Network diagram for local MAC authentication configuratio
IP network
L2 switch
FAT AP
Client
Configuration procedure
1) Select a correct country/region code
Select Advanced > Country/Region Code from the navigation tree to enter the page for setting a
country/region code, as shown in
Figure 3-2.
2) Configure a wireless service
# Create a wireless service.
Select Wireless Service > Access Service from the navigation tree, and click New to enter the page
for creating a wireless service, as shown in
Figure 3-17:
Figure 3-17 Create a wireless service
z Set the service name to mac-auth.
z Select the wireless service type clear.
z Click Apply.
3) Configure the wireless service
After you have created a wireless service, you will enter the wireless service configuration page. You
need to perform security setup when configuring MAC authentication, as shown in
Figure 3-18:
