xi
F
IGURES
1-1 CS/2500 and CS/2600 Communications Servers 1-1
1-2 CS/2500 Series Enclosure 1-3
1-3 CS/2500 Front Panel 1-5
1-4 CS/2600 Front Panel 1-5
1-5 CS/2500 and CS/2600 Back Panel 1-7
1-6 Power Supply Module 1-10
2-1 Mounting in a Rack 2-3
2-2 Console Port Cable Attachment 2-6
2-3 Printer Port Cabling 2-8
5-1 Removing the Fuseholder Cartridge 5-3
5-2 Opening the Fuseholder Cartridge 5-4
5-3 Removing the Server Cover 5-6
5-4 Server Components 5-7
5-5 Memory Chip and EPROM Locations on Motherboard 5-8
5-6 Removing the Diskette Drive 5-9
5-7 Removing the Power Supply 5-12
A-1 Serial Connector Pin Numbering A-1
A-2 Cable Wiring for Serial Port in Regular RS-422 Mode A-3
A-3 Cable Wiring for Serial Port in Automatic RS-422 Selection Mode A-4
A-4 Transceiver Connector Pin Numbers A-4
A-5 Printer Port Pin Numbers A-5
