3Com CS/2500 - Opening the Fuseholder Cartridge

5-4 C
HAPTER
5: M
AINTENANCE AND
U
PGRADES
8 Reinstall the fuseholder cartridge in the receptacle.
Figure 5-2 Opening the Fuseholder Cartridge
Autoranging
power module
Pull up
plastic
retainer
Fuse
Fuse clip
insert
Fuseholder
cartridge
Flip
