Optional Rack Mount Kit 1-11
Figure 1-6 Power Supply Module
Optional Rack
Mount Kit
An optional rack mount kit is available for CS/2500 series servers
(3Com part number 3C759). This kit allows you to mount the server in a
two- or four-pole 19-inch rack.
For information on how to install the server in a rack, refer to
“Mounting in a Rack” on page 2-2.
Specifications
This section describes CS/2500 and CS/2600 exterior hardware
specifications, electrical requirements, and environmental requirements.
The following tables list the CS/2500 series physical dimensions,
electrical requirements, and environmental conditions recommended for
safe, reliable operation.
Fuse holder
cartridge
Power cord
receptacle
AC switch
Table 1-4 Physical Dimensions
Attribute Description
Length 12.6 in (32.3
cm)
Width 16.2 in (41.1
cm)
Height 3.8 in (9.6 cm)
CS2500BookFile : Overview Page 11 Thursday, December 11, 1997 10:44 AM
