A-6 A
PPENDIX
A: P
IN
A
SSIGNMENTS
8 8 Data7 Server Data Bit 6
9 9 Data8 Server Data Bit 7
10 10 Acknowledge Printer —
11 11 Busy Printer —
12 12 Out of paper Printer —
13 13 SLCT Printer —
14 14 Unassigned — —
15 32 Error Printer —
16 31 Initialize Printer —
17 36 Unassigned — —
18 33 Signal ground — —
19 19 Signal ground — —
20 21 Signal ground — —
21 23 Signal ground — —
22 25 Signal ground — —
23-25 — Signal ground — —
Table A-3 Printer Port Pin Assignments (continued)
Pin (Server
Interface)
Pin (Printer
Interface)
Signal Source Description
CS2500BookFile : PinAssignments Page 6 Thursday, December 11, 1997 10:44 AM
