Pannoramic DESK 1.18.1 User’s Guide 4 Software Description
Functions
• To move the specimen holder to load/unload position, click . You can replace
the slide when it is in this position.
Caution!
Ensure that the slide is not tilted, and that it rests perfectly horizontally
on the stage.
To display an image of the barcode area, click . You can redefine the barcode reading
area by dragging the edges of the green square.
To check whether the barcode reading settings are correct, display the barcode digits in the Barcode
field by clicking .
Note:
If you did not set the barcode type correctly, or there is no barcode in
the barcode area, the software will display the following error
message: “Barcode detection unsuccessful! There might be no barcode
present.”
1D Barcode Types
You can select the following 1D barcode types:
• Code 128
• Code 93
• EAN 8
• EAN 13
• UPC-A
May 29, 2014 - Rev. 1 3DHISTECH Ltd.
28(77)
