Pannoramic DESK 1.18.1 User’s Guide 4 Software Description
Figure 35 – Focus level and step size
4.3.6 Service tab
Figure 36 – Service tab
This tab contains control and maintenance functions.
Emergency Manual Slide Removal Position
The specimen holder will be moved to a position where the slide can be removed manually
after opening the cover (see section 5.3.1 Removing the protective cover ).).
Slide Removed Manually
Click this button to notify the software that you have removed the slide manually.
Show images during scanning
If you select this option, you will be able to see the currently scanned image field during
scanning in the live image display field. This slows down digitization process and should be
activated only with purpose.
May 29, 2014 - Rev. 1 3DHISTECH Ltd.
54(77)
