3D Systems CubePro - At a Glance

43D Systems, Inc.
3
AT A GLANCE
EXTRUDER CARRIAGE ASSEMBLY
A
Delivery Tube Bracket
B
Delivery Tube Nut 1
C
Delivery Tube 1
D
Delivery Tube Nut 2
E
Delivery Tube 2
F
Delivery Tube Nut 3
G
Delivery Tube 3
H
Delivery Tube Block
I
Extruder 1
J
Extruder 2
K
Extruder 3
L
Print Jet Cooling Fan
M
Creation Cooling Fan
Front
B
D
F
H
I
J
K
M
A
L
M
C
E
G
