Select the upper right corner of the triangle on the touchscreen display.2.
NOTE: The printheads will move to the right rear corner of the print pad.
Using the designated page from the Setup/Repack instructions, slide the paper3.
between the print jets and the print pad.
NOTE: If there is a slight resistance, proceed to step 5.
NOTE: The red line (C) illustrates the gap between the print jets (A) and the
print pad (B).
If the paper slides easily between the print jets and print pad, rotate the adjustment4.
