Specifi cations
1. Tape:
For use with Scotch
®
pressure-sensitive fi lm box sealing tapes.
2. Tape Width:
48mm [2 inches] minimum to 72mm [3 inches] maximum.
3. Tape Roll Diameter:
Up to 405mm [16 inches] maximum on a 76.2mm [3 inch] diameter core.
(Accommodates all system roll lengths of Scotch
®
fi lm tapes.)
4. Tape Application Leg Length - Standard:
70mm ± 6mm [2-3/4 inches ±1/4 inch]
Tape Application Leg Length - Optional:
50mm ± 6mm [2 inches ± 1/4 inch] (See "Adjustments – Tape Leg Length.")
5. Box Size Capacities:
For use with center seam regular slotted containers.
Minimum Maximum
Length – 150mm [6 inches] Unlimited
Height – 120mm [4-3/4 inches] (most “3M-Matic” Case Sealers)
90mm [3-1/2 inches] (with optional 2 inch leg length)
Width – 150mm [6 inches]
When upper and lower taping heads are used on “3M-Matic” case sealers, refer to the respective instruction
manual specifi cations for box weight and size capacities.
6. Operating Rate:
Conveyor speeds up to 0.5 m/s [100 feet per minute].
7. Operating Conditions:
Use in dry, relatively clean environments at 5° to 40° C [40° to 105° F] with clean dry boxes.
Important – Taping heads should not be washed down or subjected to conditions causing moisture
condensation on components.
8. Taping Head Dimensions:
Length – 442 mm [17 3/8 inches]
Height – 648 mm [25 1/2 inches] (with tape drum)
Width – 130 mm [5-1/8 inches] (without mounting spacers)
Weight – Packaged: 8.2 kg [18 lbs.] Unpackaged: 7.3 kg [16 lbs.]
Limited by
Case Sealer
AccuGlide 3 Taping Head - 3"
