AccuGlide 3 Taping Head - 3"
33
Figure 10402 – 3" Latch Upper and Lower Heads
Ref. No. 3M Part No. Description
10402-1 78-8070-1395-4 Bracket – Bushing Assembly
10402-2 78-8060-8462-6 Shaft – Tape Drum, 3 Inch Head
10402-3 78-8017-9169-6 Nut – M18 x 1
10402-4 78-8098-8829-6 Tape Drum Sub Assembly – 3 Inch Wide
10402-5 78-8098-8828-8 Tape Drum
10402-6 78-8098-8830-4 Leaf Spring
10402-7 26-1002-5753-9 Screw – Self Tapping
10402-8 78-8060-8172-1 Washer – Friction
10402-9 78-8052-6271-0 Washer – Tape Drum
10402-10 78-8100-1048-4 Spring – Core Holder
10402-11 78-8017-9077-1 Nut – Self Locking, M10 x 1
10402-12 78-8100-1050-0 Spacer – Bracket
10402-13 26-1003-5829-5 Screw – Hex Hd, M6 x 12
10402-14 78-8133-9641-9 Tape Drum Assembly – 3 Inch Head
10402-15 26-1004-5510-9 Washer – Plain, M10
10402-16 78-8098-8816-3 Latch – Tape Drum
10402-17 78-8052-6651-3 Washer - Nylon
