49
Special Set-Up Procedure (continued)
Box Height Range – (Refer to Figure 13-11 / Section 7.4 / and Specifi cations)
The operating range of the upper drive assembly can be adjusted to minimize its movement (which increases
the operating speed) and in conjunction with adjusting the bed height, to change the range of box heights being
sealed.
After establishing the minimum box height to be sealed, position the stop bumpers as follows:
1. Latch upper drive assembly in upper position, turn off air and electric.
2. Remove and relocate the stop bumper assembly to the desired position on both side columns. Be sure that
the stop bumpers are reassembled as shown and secure (See Figure 13-11 and Figure 15266).
3. Turn on the air and electrical power to the case sealer. The upper taping head will now descend only part
way thus increasing operating speed.
700rks
2010 January
• To reduce the risk associated with mechanical and electrical hazards:
− Turn electrical and air supply off and disconnect before performing any adjustments,
maintenance or servicing the machine or taping heads
− Allow only properly trained and qualifi ed personnel to operate and/or service this equipment
WARNING
• To reduce the risk associated with muscle strain:
− Use proper body mechanics when removing or installing taping heads that are moderately
heavy or may be considered awkward to lift
WARNING
