3M 40800 - Page 83

71
700rks
Figure 15265/1
Ref. No. 3M Part No. Description
15265-1 78-8137-0978-5 Bottom Drive Assy - w/Motor
15265-2 78-8137-0579-1 Frame - Drive
15265-3 78-8137-0568-4 Spacer
15265-4 26-1003-5829-5 Screw Hex Hd. M6 X 12
15265-7 78-8052-6710-7 Roller - Idler
15265-8 78-8052-6709-9 Washer - Special
15265-9 78-8010-7435-8 Washer - Metric Lock, M6
15265-10 26-1003-7957-2 Screw Soc. Hd. Hex Hd. M6 X 16
15265-11 78-8070-1518-1 Spacer - Shaft
15265-12 26-1003-6918-5 Nut, Plastic Insert M10 Hex Flange
15265-13 78-8070-1519-9 Screw - Soc. Hd. Hex. Hd. M8 X 70
15265-14 78-8017-9318-9 Washer - Plain - Metric 8MM
15265-15 78-8070-1520-7 Guide - Drive Belt
15265-16 26-1005-4757-4 Screw - Flat Hd, Soc. Dr. M5 X 20
15265-17 78-8137-0960-3 Support - Gear Box
15265-18 26-1003-7964-8 Screw Soc. Hd. Hex Soc. Dr., M8 X 20
15265-19 78-8137-0580-9 Support - Motor Bottom
15265-20 26-1011-8828-7 Capacitor - 115V Gear Motor
15265-21 78-8070-1523-1 Screw 1/4-28X3/4
15265-22 78-8042-2919-9 Washer - Triple, M6
15265-23 78-8137-0936-3 Sprocket - 3/8" Z=24
15265-24 78-8137-0940-5 Screw - Set M6 x 20
15265-25 78-8137-0962-9 Cover
15265-26 78-8010-7209-7 Screw, Soc. Hd. M6 X 12
15265-27 26-1000-0010-3 Washer - Flat M6
15265-28 78-8076-4562-3 Cover - Bottom
15265-29 26-1003-5820-4 Screw - Hex Hd. M5 X 12
15265-30 78-8005-5741-1 Washer - Flat, M5
15265-31 78-8137-0570-0 Shaft with Drive Pulleys
15265-32 78-8137-0537-9 Shaft - Gearbox
15265-33 78-8057-5811-3 Key, 6 X 6 X 20MM.
15265-34 78-8054-8986-7 Sprocket - 3/8" Pitch, 28 Teeth
2010 January
700rks-NA
