3M S15 - Table of Contents; Contents

2
About this manual . . . . . . . . . . 1
Contents . . . . . . . . . . . . . . . . . 2
Projector feature
s . . . . . . . . . . 3
About contents of package
. . 3
Part name
s . . . . . . . . . . . . . . . 4
Projector . . . . . . . . . . . . . . . . . . . . . 4
Controls . . . . . . . . . . . . . . . . . . . . . . 5
Remote control . . . . . . . . . . . . . . . . 5
Preparations . . . . . . . . . . . . . .
6
Fastening the lens cover . . . . . . . . . 6
Putting batteries . . . . . . . . . . . . . . . 7
Using the remote control . . . . . . . . . 8
About the filter cover for bottom-up use . . . 9
Setting up . . . . . . . . . . . . . . . 10
Arrangement . . . . . . . . . . . . . . . . . .11
Adjusting the projector's elevator . . . 12
Connecting your devices . . . . . . . . 13
Connecting power supply . . . . . . . 15
Power on/of
f . . . . . . . . . . . . . 16
Turning on the powe
r . . . . . . . . . . . 16
Turning off the power . . . . . . . . . . . 17
Operating . . . . . . . . . . . . . . . 18
Adjusting the volume . . . . . . . . . . . 18
Temporarily muting the soun
d . . . . 18
Selecting an input signal . . . . . . . . 18
Searching an input signal . . . . . . . 19
Selecting an aspect ratio . . . . . . . . 19
Adjusting the zoom (magnifying
power) . . . . . . . . . . . . . . . . . . . . . . 19
Adjusting the focus . . . . . . . . . . . . 19
Using the automatic adjustment
feature . . . . . . . . . . . . . . . . . . . . . . 20
Adjusting the position . . . . . . . . . . 20
Correcting the keystone distortions . . . 20
Using the partial magnify feature . . . 21
Freezing the screen . . . . . . . . . . . . 21
Temporarily blanking the screen . . . 21
Multifunctional settings . . . . 22
Using the menu function . . . . . . . . 22
Contents
Contents
EASY MENU . . . . . . . . . . . . . . . . . 25
Aspect, Zoom, Keystone, Mode,
Bright, Contrast, Color, Tint,
Sharpness, Whisper, Mirror, Reset,
Filter time, Language,
Go to advanced menu
PICTURE menu . . . . . . . . . . . . . . . 27
Bright, Contrast, Gamma, Color temp,
Color, Tint, Sharpness, Progressive,
My memory
IMAGE menu . . . . . . . . . . . . . . . . . 30
Aspect, Over scan, V. position,
H. position, H. phase, H. size,
Auto adjust execute
INPUT menu . . . . . . . . . . . . . . . . . 32
Color space, Video format, Frame lock,
Information
SETUP menu . . . . . . . . . . . . . . . . . 34
Zoom,
Keystone, Whisper, Mirror,
Volume
SCREEN menu . . . . . . . . . . . . . . . 35
Language, Menu position, OSD bright,
Blank, Start up, MyScreen,
MyScreen lock, Message
OPTION menu . . . . . . . . . . . . . . . . 38
Auto search, Auto off, Lamp time,
Filter time, Service
Maintenance . . . . . . . . . . . . . 41
Lamp . . . . . . . . . . . . . . . . . . . . . . . 41
Air filte
r . . . . . . . . . . . . . . . . . . . . . 43
Other care . . . . . . . . . . . . . . . . . . . 45
Troubleshootin
g . . . . . . . . . . 46
Related messages . . . . . . . . . . . . . 46
Regarding the indicator lamps . . . . 48
Phenomena that may easily be
mistaken for machine defects . . . . 50
Specification
s . . . . . . . . . . . . 52
Accessories . . . . . . . . . . . . . 54
Technical . . . . . . . . . . . . . . . 55
© 3M 2005. 3M™ Digital Projector S15/X15
