Part names
Lens (

1
6
, 45
)
Lens cover (

6
, 16
)
Filter cover (

9, 1
0
, 43
)
(Air filter and intake vent
are inside.)
Elevator button
(

12
)
Elevator foot (

12
)
Remote sensor (

8
)
Focus ring (

1
9
)
Vent (

10
)
AC inlet (

1
5
)
Power switch (

1
6
, 17
)
Elevator button (

12
)
S-VIDEO port
(

1
4, 18, 19
)
VIDEO port (

1
4, 18, 19
)
CONTROL port (

1
4
)
Part names
Projector
Lamp door (

42
)
(Lamp unit is inside.)
Elevator foot (

12
)
Bottom side
Speaker
Front-Right side
Rear-Left side
Control buttons (

5
)
Ports
(See below.)
Vent (

10
)
Ports
AUDIO port (

1
4
)
Restart switch (

17
)
RGB port (

1
4, 18, 19
)
Kensington lock slot
