Specifications
NOTE • This specifications are subject to change without notice.
Warranty and after-service / Specifications
Item Specification
Product name Liquid crystal projector
Liquid
Crystal
panel
Panel size
S15:1.4cm (0.55 type)
X15:1.5cm (0.6 type)
Drive system TFT active matrix
Pixels
S15 : 480,000 pixels (800 horizontal x 600 vertical)
X15 : 786,432 pixels (1,024 horizontal x 768 vertical)
Lens
S15 : F=1.65 f=20.4 mm
X15 : F=1.77 f=20.7 mm
Lamp 165W UHB
Power Supply AC100-120V/2.7A, AC220-240V/1.5A
Power Consumption 240W
Temperature range
5 ~ 35°C (Operating)
Size
285 (W) x 73 (H) x 202 (D) mm
(Not including protruding parts)
• Please refer to the following figure.
Weight (mass)
2.2 kg
Ports
RGB input:
RGB .......D-sub 15pin mini x 1
Communication port:
CONTROL .......... D-sub 9pin x 1
Video input:
VIDEO ...................... RCA x 1
S-VIDEO .............S-Video x 1
Audio input:
AUDIO ...........
Stereo mini x 1
