USER’S MANUAL OF WNAP 3G MOBILE ROUTER Version: 2.0
1
1 Introduction
The WNAP 3G Mobile Router is an affordable IEEE 802.11b/g with 802.11n specifications of
Wireless LAN router solution; setting SOHO and enterprise standard for high performance,
secure, manageable and reliable WLAN.
This document describes the steps required for the initial IP address assign and other WLAN
router configuration. The description includes the implementation of the above steps.
1.1 Package contents
The package of the WNAP 3G Mobile Router includes the following items,
9 The WNAP 3G Mobile Router
9 The DC Power Adapter
9 The Documentation CD
9 RJ-45 Cable Line (Option)
1.2 Product Features
Generic Router
¾ Compatible with IEEE 802.11n Specifications provides wireless speed up to
300Mbps data rate.
¾ Compatible with IEEE 802.11g high rate standard to provide wireless Ethernet
speeds of 54Mbps data rate.
¾ Maximizes the performance and ideal for media-centric applications like streaming
video, gaming and Voice over IP technology.
¾ Supports multi-operation (bridge/gateway/WISP) modes between wireless and
wired Ethernet interfaces.
¾ Supports WPS, 64-bit and 128-bit WEP, WPA, WPA2 encryption/decryption and
WPA with Radius function to protect the wireless data transmission.
¾ Supports IEEE 802.1x Authentication.
¾ Supports IEEE 802.3x full duplex flow control on 10/100M Ethernet interface.
¾ Supports DHCP server to provide clients auto IP addresses assignment.
¾ Supports DHCP client, static IP, PPPoE, PPTP L2TP, GSM 3.5G of WAN Interface.
¾ Supports firewall security with Port filtering, IP filtering, MAC filtering, Port
forwarding, DMZ hosting, URL filtering and Virtual Server functions.
¾ Supports WEB based management and configuration.
¾ Supports UPnP for automatic Internet access.
¾ Supports Dynamic DNS service.
¾ Supports NTP client service.
