USER’S MANUAL OF WNAP 3G MOBILE ROUTER Version: 2.0
16
3.3.3 Operation Mode
This page is used to configure which mode wireless broadband router acts
Screen snapshot – Operation Mode
Item Description
Gateway Traditional gateway configuration. It always connects internet via
ADSL/Cable or 3G USB modem. LAN interface, WAN interface,
Wireless interface, NAT/Firewall modules are applied to this mode
Bridge Each interface (LAN, WAN and Wireless) regards as bridge. NAT,
Firewall and all router’s functions are not supported
Wireless ISP Switch Wireless interface to WAN port and all Ethernet ports in
bridge mode. Wireless interface can do all router’s functions
Apply Changes Click the Apply Changes button to complete the new configuration
setting.
Reset Click the Reset button to abort change and recover the previous
configuration setting.
