USER’S MANUAL OF WNAP 3G MOBILE ROUTER Version: 2.0
18
Network Type
While Mode is selected to be Client. Click to select the
network type infrastructure or Ad hoc.
SSID It is the wireless network name. The SSID can be 32 bytes long.
Channel Width Select the operating channel width 20 MHz or 40 MHz.
[N band only]
Control Sideband Select the Sideband with Upper or Lower for channel width 40MHz.
[N band only]
Channel Number Select the wireless communication channel from pull-down menu.
Broadcast SSID Click to enable or disable the SSID broadcast function.
Refer to 4.14 What is SSID Broadcast?
WMM
Click Enabled/Disabled to init WMM feature. [ B/G/B+G Mode
only]
Data Rate Select the transmission data rate from pull-down menu. Data rate can
be auto-select, 1M to 54Mbps or MCS.
Refer to 4.32 What is Modulation Coding Schemes
(MCS)?
Associated Clients Click the Show Active Clients button to open Active Wireless Client
Table that shows the MAC address, transmit-packet, receive-packet
and transmission-rate for each associated wireless client.
Enable Mac Clone (Single
Ethernet Client)
Take Laptop NIC MAC address as wireless client MAC address.
[Client Mode only]
Enable Universal Repeater
Mode
Click to enable Universal Repeater Mode
SSID of Extended Interface Assign SSID when enables Universal Repeater Mode.
Apply Changes Click the Apply Changes button to complete the new configuration
setting.
Reset Click the Reset button to abort change and recover the previous
configuration setting.
