USER’S MANUAL OF WNAP 3G MOBILE ROUTER Version: 2.0
37
subnet mask for it.
Default Gateway If you select the Static IP support on WAN interface, fill in the
default gateway for WAN interface out going data packets.
MTU Size Fill in the mtu size of MTU Size. The default value is 1500
DNS 1 Fill in the IP address of Domain Name Server 1.
DNS 2 Fill in the IP address of Domain Name Server 2.
DNS 3 Fill in the IP address of Domain Name Server 3.
Clone MAC Address Fill in the MAC address that is the MAC address to be cloned. Refer
to 4.24 What is Clone MAC Address?
Enable uPNP Click the checkbox to enable uPNP function.
Refer to 4.22 What is Universal Plug and Play (uPNP)?
Enable IGMP Proxy Click the checkbox to enable IGMP Proxy.
Enable Ping Access on
WAN
Click the checkbox to enable WAN ICMP response.
Enable Web Server Access
on WAN
Click the checkbox to enable web configuration from WAN side.
Enable FTP Server Access
on WAN
Click the checkbox to enable FTP Server Access on WAN
Enable IPsec pass through
on VPN connection
Click the checkbox to enable IPSec packet pass through
Enable PPTP pass through
on VPN connection
Click the checkbox to enable PPTP packet pass through
Enable L2TP pass through
on VPN connection
Click the checkbox to enable L2TP packet pass through
Apply Changes Click the Apply Changes button to complete the new configuration
setting.
Reset Click the Reset button to abort change and recover the previous
configuration setting.
