Embedded Controller
B O X E R - 6614
Chapter 2 Hardware Installation
2 - 31
Pin
Pin Name
Signal Type
Signal Level
1
+5VSB
PWR
+5V
2
USB0_D-
DIFF
3
USB0_D+
DIFF
4
GND
GND
5
USB0_SSRX−
DIFF
6
USB0_SSRX+
DIFF
7
GND
GND
8
USB0_SSTX−
DIFF
9
USB0_SSTX+
DIFF
10
+5VSB
PWR
+5V
11
USB1_D-
DIFF
12
USB1_D+
DIFF
13
GND
GND
14
NC
15
NC
16
GND
GND
17
NC
18
NC
Note: Only Port0 supports USB3.0.
